Circuit Diagram
...
Heater & A/C Control Unit (DATC) Replacement
1.
Disconnect the negative (-) battery terminal.
2.
Using a screwdriver or remover, remove the center fascia panel
(A).
...
Specifications
Items
Specification
Rated voltage
DC 12V
Operating voltage
9V ~ 16V
Operating speed
30㎞/h ~ 250㎞/h
...
