1. |
Check the power Tailgate module input/output value by using the
GDS. If the operation of power Tailgate module is abnormal, replace
power trunk drive unit.
|
2. |
To check the DTC of the power trunk module, select "PTM"
|
3. |
Select "Input/output monitoring".
|
ESC Control Module Components
1. Front - left tube
2. Rear - right tube
3. Rear - left tube
4. Front - right tube
5. MC2
6. MC1
7. ESC control module (HECU)
8. Bracket
...
Cluster Ionizer Replacement
1.
Disconnect the negative (-) battery terminal.
2.
Remove the glove box housing.
(Refer to Body -"Crash Pad")
...
Specification
Accelerator
Position
Output Voltage (V)
APS1
APS2
C.T
0.7 ~ 0.8
0.275 ~ 0.475
W.O.T
3.8 ~ 4.4
1.75 ~ 2.35
...
